Chisel soldering tip 90° 3 mm for TMT-9000S - Thermaltronics M7CH181
Chisel soldering tip 3 mm at 90° for the SHP-1 ESD handpiece of the Thermaltronics Curie-heat stations TMT-9000S, MX-500, MX-5000 and MX-5200. Working temperature 350 - 398 °C, lead-free and RoHS compliant. Direct replacement for the Metcal tip STTC-113.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The M7CH181 is a chisel-shaped soldering tip 3 mm wide at a 90° angle for the SHP-1 ESD handpiece of the Thermaltronics Curie-heat soldering stations. It transfers heat across a wide contact face for clean, fast joints within the 350 - 398 °C working range.
Benefits
- Chisel geometry 3 mm at 90° for even heat transfer to pads and component leads
- Curie-heat technology holds the tip temperature in the 350 - 398 °C range without manual control
- Lead-free and RoHS compliant, suited to modern lead-free soldering
- Direct replacement for the Metcal tip STTC-113
Applications
General hand and rework soldering of through-hole and SMD components, drag soldering and PCB rework in electronics manufacturing.
Compatibility and scope of delivery
Fits the SHP-1 handpiece of the TMT-9000S-1, TMT-9000S-2, MX-500, MX-5000 and MX-5200 stations. Supplied as a single tip.
ESD safe, lead-free, RoHS compliant. Country of origin USA.
Technical data
| Item no. | WL37866 |
|---|---|
| Manufacturer item no. | M7CH181 |
| Tip shape | chisel |
| Angle | 90° |
| Tip width | 3 mm (0,12 in) |
| Tip length | 5,2 mm (0,2 in) |
| Temperature range | 350 - 398 °C |
| Compatible handpiece | SHP-1 |
| Product series | M soldering tip series |
| Replaces Metcal | STTC-113 |
| Weight | 0.015 kg |
| Manufacturer | Thermaltronics |
| Manufacturer Nr. | M7CH181 |
| HS-Code | 85159080 |
| GPSR manufacturer information | AMS Ltd, Unit 3 Norse Trade Park, Congleton CW12 1GW, www.ams-electronics.co.uk |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | China |
| ESD version | ESD (antistatic) |
| Tip diameter/width [mm] | 3 |
| Soldering tip shape | meißelförmig |
| Series | M |
