Soldering tip chisel extra large 5,0mm (0,20") for SHP-1, 420 to 475 °C - Thermaltronics M8LC650

Name: Soldering tip chisel extra large 5,0mm (0,20") for SHP-1, 420 to 475 °C - Thermaltronics M8LC650
Brand: Thermaltronics
SKU: WL37992
Price: 16.81 EUR
Availability: InStock

Thermaltronics ✓ Original product Brand new Made in United States

Replaceable M-series soldering tip chisel extra large 5,0mm (0,20") for the SHP-1 handpiece, tip width 5 mm (0,2 in). Operating temperature 420 to 475 °C, RoHS compliant and lead-free. Fits TMT-9000S and Metcal MX-500, MX-5000 and MX-5200.

Net

€16.81

excl. VAT

Item WL37992

Manufacturer no. M8LC650

Question about this item

Datasheet (PDF)

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

The M8LC650 soldering tip replaces worn M-series tips on the SHP-1 handpiece without reconfiguring the soldering unit. With a tip width of 5 mm (0,2 in) and a chisel extra large 5,0mm (0,20") geometry it suits targeted lead-free soldering across the 420 to 475 °C range.

Benefits

Tip width 5 mm (0,2 in) for the right thermal coupling to the joint
Operating temperature 420 to 475 °C of the M soldering tip series
RoHS compliant and lead-free
Changed on the SHP-1 handpiece without tools
Replaces Metcal article no. STTC-865

Applications

Lead-free hand and rework soldering of electronic assemblies, repair and rework on printed circuit boards.

Compatibility & scope of delivery

Compatible handpiece: SHP-1
Suitable for: TMT-9000S-1, TMT-9000S-2, MX-500, MX-5000, MX-5200
Scope of delivery: 1 soldering tip M8LC650

RoHS compliant, lead-free, ESD-safe in use. Manufacturer: Thermaltronics (USA).

Technical data

Article no.	WL37992
Model / manufacturer no.	M8LC650
Manufacturer	Thermaltronics
Product series	M soldering tip series
Temperature range	420 to 475 °C
Tip width	5 mm (0,2 in)
Tip length	11,4 mm (0,45 in)
Compatible handpiece	SHP-1
Order unit	piece
Replaces Metcal	article no. STTC-865
Weight	0.100000
Manufacturer Nr.	M8LC650
HS-Code	85159080900
GPSR manufacturer information	AMS Ltd, Unit 3 Norse Trade Park, Congleton CW12 1GW, www.ams-electronics.co.uk
Condition of article	New
Article authenticity	Original product
Country of Manufacture	United States
ESD version	ESD (antistatic)
Tip diameter/width [mm]	5.000000
Soldering tip shape	meißelförmig
Series	M
