When removing through-hole parts, the inner diameter of the tip decides whether the residual solder is drawn off in one pass. The T60DT007 offers a 2.40 mm bore and a Curie-controlled working range of 325 to 358 °C. It fits the DS-GUN-2 desoldering handpiece used on the TMT-5000S-1 and TMT-5000S-2 stations.
Desoldering tip D type inner diameter 2.40 mm T series - Thermaltronics T60DT007
THERMALTRONICS
Original product
Net price (excl. VAT)
€26.36
Item
WL38322
Manufacturer no.
T60DT007
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.T60DT007
ConditionNew
Article
WL38322
Frequently Bought Together
-
This Item:
€26.36
-
Soldering tip hoof 60° 3.3 mm T series - Thermaltronics TM80DS525
€24.29
-
Soldering tip chisel 1.6 mm 30 degrees T80 series - Thermaltronics T80CH016
€13.25
Total price
Through-hole components come out cleanly only if the desoldering tip surrounds the lead with a little clearance. The Thermaltronics T60DT007 from the T desoldering tip series provides a 2.40 mm inner diameter and holds 325 to 358 °C through its Curie point heater.
Benefits
- 2.40 mm bore suits the heavier leads of power and industrial THT parts
- Self-regulating Curie point heating, 325-358 °C working range with no trimming at the station
- 13 mm tip length reaches between tall neighbouring components
- Lead-free operation, RoHS compliant
- Tool-free change in the DS-GUN-2 desoldering handpiece
Technical data
| Item number | WL38322 |
| Model | T60DT007 |
| Manufacturer | Thermaltronics |
| Manufacturer item number | T60DT007 |
| Product series | T desoldering tip series, 325-358 °C |
| Type | Desoldering tip |
| Temperature range | 325-358 °C |
| Tip width | 2.4 mm (0.09 in) |
| Tip length | 13 mm (0.51 in) |
| Suitable handpiece | DS-GUN-2 |
| Suitable stations | TMT-5000S-1, TMT-5000S-2 |
| Compliance | RoHS, lead-free |
| Dimensions with packaging (LxWxH) | 175 mm x 19 mm x 19 mm (6.9 in x 0.7 in x 0.7 in) |
| Weight | 0.1 kg |
| Order unit | Piece |
Applications
Removing connectors, electrolytic capacitors, relays and terminal blocks in repair work and prototyping. The 2.40 mm bore matches the thicker pins found in power and industrial electronics.
Compatibility and scope of delivery
The cartridge belongs to the T desoldering tip series and is used in the DS-GUN-2 handpiece of the TMT-5000S-1 and TMT-5000S-2 desoldering stations. Supplied as one desoldering tip without handpiece or station.
| Manufacturer Nr. | T60DT007 |
|---|---|
| Manufacturer | Thermaltronics |
| Weight | 0.100000 |
| GPSR manufacturer information | AMS Ltd, Unit 3 Norse Trade Park, Congleton CW12 1GW, www.ams-electronics.co.uk |
| Article authenticity | Original product |
| Condition of article | New |
| Series | T |
| Position sensing | No |
| Shank inner diameter [mm] | 2.400000 |
