Blade shaped T series cartridge with a 4.83 mm working face and a tinned area extended to 5.84 mm. The extra solder reservoir makes it the working tip for drag soldering SOIC and QFP rows. Operates at 420-475 °C on the SHP-T hand piece of the TMT-5000S-1 and TMT-5000S-2 stations.
Soldering tip blade 4.83 mm with enlarged 5.84 mm tinned area, T series - Thermaltronics TM80DS526
THERMALTRONICS
Original product
Net price (excl. VAT)
€24.29
Item
WL38513
Manufacturer no.
TM80DS526
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.TM80DS526
ConditionNew
Article
WL38513
Frequently Bought Together
-
This Item:
€24.29
-
Soldering tip knife shape 4.70 mm T series - Thermaltronics T80K047
€24.29
-
Soldering tip conical 0.10 mm micro fine T series - Thermaltronics TM70C001
€18.61
Total price
Ground planes, wide pads and connector rows need a tip that carries reserve heat and solder. The TM80DS526 is a blade tip 4.83 mm wide with the tinned area extended to 5.84 mm, so it holds noticeably more solder during drag soldering.
Benefits
- Enlarged 5.84 mm tinned area keeps more solder on the tip and cuts down on refeeding
- 4.83 mm blade working face suited to drag soldering SOIC and QFP rows
- T series cartridge technology with a 420-475 °C working range, no calibration required
- 16 mm tip length gives access between closely placed components
- Lead-free and RoHS compliant, matched to SAC alloys with high heat demand
Technical data
| Item number | WL38513 |
| Model | TM80DS526 |
| Manufacturer | Thermaltronics |
| Manufacturer item number | TM80DS526 |
| Product series | T tip series, 420-475 °C |
| Temperature range | 420-475 °C |
| Type | Soldering tip |
| Tip length | 16 mm |
| Tip length in inches | 0.63 in |
| Tip width | 4.83 mm |
| Tip width in inches | 0.19 in |
| Tip shape | Blade / knife |
| Tinned area | 5.84 mm (0.23 in) |
| Matching hand piece | SHP-T |
| Dimensions with packaging (LxWxH) | 117 mm x 33 mm x 13 mm |
| Dimensions with packaging in inches (LxWxH) | 4.6 in x 1.3 in x 0.5 in |
| Order unit | Piece |
| Weight | 0.1 kg |
| Compliance | RoHS compliant, lead-free |
Applications
Drag soldering fine pitch packages, clearing solder bridges, attaching stranded wire and shielding cans, and every joint where thermal mass overwhelms a narrow conical tip.
Compatibility and scope of delivery
For Thermaltronics TMT-5000S-1 and TMT-5000S-2 soldering stations used with the SHP-T hand piece. Supplied as a single TM80DS526 cartridge in a protective tube.
| Manufacturer Nr. | TM80DS526 |
|---|---|
| Manufacturer | Thermaltronics |
| Weight | 0.100000 |
| GPSR manufacturer information | AMS Ltd, Unit 3 Norse Trade Park, Congleton CW12 1GW, www.ams-electronics.co.uk |
| Article authenticity | Original product |
| Condition of article | New |
| Series | T |
| Tip diameter/width [mm] | 4.830000 |
