Power supply 32/40 V for SKD-BN800 and SKD-TBK screwdrivers - Kilews SKP-40B-HLN

A brushless low-voltage screwdriver is only as steady as its supply. The SKP-40B-HLN accepts 100 to 240 V and outputs either 32 or 40 V DC, selected with the LO and HI switch on the unit.

What the power supply delivers

• Wide range input of 100 to 240 V at 50 and 60 Hz, usable at any site.
• Two output steps of 32 and 40 V DC, preselected by switch and giving two speed levels at the driver.
• Designed for the brushless SKD-BN800, SKB-BE800 and SKD-TBK20/30/50 series.
• Bench housing of 213 x 133 x 68 mm that stands beside the workstation or under the bench.

Technical data

Applications

Manual assembly workstations in electronics and equipment manufacturing and the integration of a driver into automated screwdriving stations. Where a counter function and program selection are needed, a controller of the SKP-BC40HLN range takes over that task.

Compatibility

Intended for screwdrivers of the SKD-BN800, SKB-BE800 and SKD-TBK20/30/50 series. The property table does not list the power supply as ESD compliant, it usually stands off the ESD work surface.
