Z-Line prefilter G4-02 series 1200 pack of 10 - ULT 02.0.663
The Z-Line prefilter G4-02 holds back coarse dust and fibres in the ULT 1200 series extraction units and relieves the downstream filter stages. Filter class ISO Coarse 90% to ISO 16890, listed by ULT as replacement filter 4-00311. The pack of ten fits the A60 and K filter modules of ACD 1200, LAS 1200 and LRA 1200.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Units of the ULT 1200 series run at a nominal operating point of 1000 m³/h at 1700 Pa and reach up to 1500 m³/h. At these air volumes the prefilter stage comes due for replacement regularly. The Z-Line prefilter G4-02 catches coarse dust and fibres and keeps the far more expensive main and adsorption stages clear. ULT lists the pack of ten under replacement filter number 4-00311 and the single piece under 4-00310.
Benefits
- Filter class ISO Coarse 90% to ISO 16890, formerly designated G4, for coarse dust separation
- Z shaped pleating for a large filter area at low initial pressure drop
- Extends the service life of the downstream particulate and adsorption stages
- Order unit of 10 pieces, so spares for several maintenance intervals sit on the shelf
- Genuine ULT part for the A60 and K filter modules of the 1200 series
Applications
The filter works in solder fume extraction with the LRA 1200 MD.18 K, in laser fume extraction with the LAS 1200 MD.18 K and in the extraction of gases, odours and vapours with the ACD 1200 MD.18 A60. In filter module K it sits behind the expanded metal prefilter and ahead of the Z-Line filter F7 and the combination filter cassette H13A8. In filter module A60 it forms the first stage ahead of the A12 adsorption cassette at the top and three A16 adsorption cassettes below.
Compatibility and scope of delivery
Suitable for the ULT extraction units ACD 1200 MD.18 A60, LAS 1200 MD.18 K and LRA 1200 MD.18 K. The host units carry protection class IP54 and a sound level of 55 to 65 dB(A) at 50 to 100 percent air performance, the ACD 1200 A60 runs at a nominal point of 450 m³/h at 2500 Pa. Each order unit contains ten Z-Line prefilters.
Technical data
| Item number | WL41006 |
|---|---|
| Model | 02.0.663 |
| Manufacturer | ULT |
| Manufacturer item number | 02.0.663 |
| ULT replacement filter number | 4-00311 (set of 10), 4-00310 (single piece) |
| Order unit | PU |
| Content unit | 10 pieces |
| Filter type | Prefilter |
| Filter designation | Z-Line filter G4-02 |
| Filter class | ISO Coarse 90% to ISO 16890 |
| Filter module | A60 (ACD), K (LAS and LRA) |
| Device series | ACD 1200 MD.18 A60, LAS 1200 MD.18 K, LRA 1200 MD.18 K |
| Weight | 0.100000 |
| Manufacturer Nr. | 02.0.663 |
| HS-Code | 84219990 |
| GPSR manufacturer information | ULT AG Am Göpelteich 1 DE-02708 Löbau www.ult.de |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
| VPE | 10 Stück |
| Norm | ISO 16890 |
| Filter class | G4 |
