Soldering tip bevelled 60° 1 x 0.51 mm, 485 °C, STTC series - Metcal STTC-846
Ceramic substrates and joints with a large thermal mass drain heat faster than a standard tip can replace it. The STTC-846 runs at a tip temperature of 485 °C and delivers that heat through a long 60° bevelled face of 1 x 0.51 mm with a tip length of 14.2 mm. It fits the MX-H1-AVA and MX-RM3E hand pieces of the Metcal MX platform.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Heavy copper planes, ceramic substrates and components tied into large ground areas pull heat out of a joint quicker than an ordinary tip can supply it. The Metcal STTC-846 answers that with a 485 °C working temperature and a long 60° bevelled face of 1 x 0.51 mm that holds a solder reservoir and drives the heat straight into the connection.
Benefits
- Tip temperature of 485 °C for high thermal mass joints and ceramic substrates
- Bevelled 1 x 0.51 mm geometry holds solder well for drag soldering and larger pads
- Long 14.2 mm tip reaches recessed or shielded joints
- Metcal SmartHeat technology regulates temperature inside the tip, with no calibration and no temperature dial
- Cartridge can be changed during operation without tools
Applications
Soldering and rework on ceramic substrates, on ground planes and shielding cans, on heavy connector pins and on through-hole parts with strong heat dissipation. The bevelled face also suits dragging solder along coarser pitch rows.
Compatibility and scope of delivery
The cartridge works with the MX-H1-AVA and MX-RM3E hand pieces and therefore with the MX-500, MX-5000 and MX-5200 power units. One STTC-846 soldering cartridge is supplied per order unit.
Technical data
| Item number | WL42628 |
|---|---|
| Model | STTC-846 |
| Manufacturer | Metcal |
| Manufacturer item number | STTC-846 |
| Product series | STTC series |
| Tip alignment | Bevelled 60°, long |
| Tip dimensions | 1 x 0.51 mm |
| Tip length | 14.2 mm |
| Tip temperature | 485 °C |
| Suitable hand piece | MX-H1-AVA, MX-RM3E |
| Order unit | Piece |
| Weight | 0.1 kg |
| Weight | 0.100000 |
| Manufacturer Nr. | STTC-846 |
| GPSR manufacturer information | OK International Ltd Eagle Close, Chandlers Ford GB-SO53 4NF Hampshire www.metcal.com |
| Condition of article | New |
| Article authenticity | Original product |
| Tip diameter/width [mm] | 1.000000 |
| Soldering tip shape | angeschrägt |
| Series | STTC |
