VARIOCUT cutting device for radially taped components, pitch 15 mm, lead 0.5 - 0.8 mm - Schleuniger

Radially taped components such as capacitors or LEDs have to be cut to length before through-hole assembly. The VARIOCUT cuts the leads straight from the tape at a pitch of 15 mm, up to 40,000 components per hour, driven only by the hand crank.

Benefits

• Up to 40,000 components per hour without power connection
• For tapes with a pitch of 15 mm
• Lead diameter 0.5 - 0.8 mm
• Wear parts such as cutting disc, cutting wheel and pin wheel can be reordered individually

Applications

Preparation of radially taped components in electronics production, prototyping and small batch manufacturing.
