Particulate filter cassette F9 380x380x345 mm series 260 - ULT 02.1.713
Particulate filter cassette in filter class F9, the wear part for ULT extraction and filter units of series 260. It sits in the MDF filter shaft and separates around 80 percent of the fine ePM1 particle fraction to ISO 16890. Replacing it on schedule keeps air volume and separation efficiency at the design value.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
A clogged pre-filter costs extraction performance long before the unit signals it. This particulate filter cassette measuring 380x380x345 mm is the matching replacement for the MDF filter shaft of the ULT series 260 and restores filter class F9 to DIN EN 779. It is the first filter stage, followed by the combination cassette with its H14 stage and activated carbon.
Benefits
- Filter class F9 to DIN EN 779, equivalent to ePM1 80 percent to ISO 16890
- Exact 380x380x345 mm format for the MDF filter shaft
- Relieves the downstream combination stage of H14 filter and activated carbon and extends its service life
- Tool-free cassette change through the filter access at the front of the unit
- Genuine ULT part, so the sealing geometry in the shaft is assured
Applications
Particle separation in series 260 extraction units serving laser processes such as engraving, marking, welding, structuring and cutting on plastics, metals and organic materials, and equally for fine dust and process aerosols at single workstations.
Compatibility and scope of delivery
Intended for ULT extraction and filter units of series 260 with an MDF filter shaft. The optical filter loading indicator on the unit signals when a change is due. Supplied as one particulate filter cassette 02.1.713 per piece.
Filter classes are stated to DIN EN 779 (F9) and ISO 16890 (ePM1 80 percent).
Technical data
| Item number | WL46858 |
|---|---|
| Model | 02.1.713 |
| Manufacturer | ULT |
| Manufacturer item number | 02.1.713 |
| Design | Particulate filter cassette F9 |
| Filter type | Pre-filter, first stage |
| Dimensions | 380x380x345 mm |
| Installation position | MDF filter shaft |
| Filter class to DIN EN 779 | F9 |
| Filter class to ISO 16890 | ePM1 80 percent |
| Series | 260 |
| Order unit | Piece |
| Weight | 10.6 kg |
| Manufacturer Nr. | 02.1.713 |
| HS-Code | 84219990 |
| GPSR manufacturer information | ULT AG Am Göpelteich 1 DE-02708 Löbau www.ult.de |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
| Norm | DIN EN 779, ISO 16890 |
| Filter class | F9 |
