Combination pliers with comfort handles, hard wire up to Ø 2.5 mm, 200 mm - Knipex 03 02 200
Combination pliers 200 mm long with comfort handles made of three ergonomic components. The longer lever cuts hard wire up to Ø 2.5 mm, medium-hard wire up to Ø 3.8 mm and multi-stranded Cu cable up to 16.0 mm². Cutting edges induction-hardened to about 60 HRC, weight 322 g.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Twenty extra millimetres of length cost little space and add noticeable leverage at the cutting edge. The 03 02 200 combination pliers cut hard wire up to Ø 2.5 mm and medium-hard wire up to Ø 3.8 mm, while comfort handles made of three components spread the hand force.
Benefits
- Long cutting edges for thicker cable, multi-stranded Cu cable up to 16.0 mm².
- Cutting edges for soft and hard wire, hard wire up to Ø 2.5 mm, medium-hard wire up to Ø 3.8 mm.
- Additionally induction-hardened edges at about 60 HRC stay sharp over a long service life.
- Gripping zones for flat and round material make the pliers versatile in use.
- Comfort handles made of three ergonomic components with two KNIPEXtend interfaces for extensions.
- 200 mm overall length at 322 g, more leverage than the 180 mm model of the same series.
Areas of use
Electrical installation, control cabinet and plant construction, assembly and maintenance. A good choice wherever hard wire up to Ø 2.5 mm is a regular part of the job.
Standards and conformity
The pliers comply with DIN ISO 5746. According to the manufacturer they contain no substances of very high concern under REACH, and the RoHS directive does not apply.
Technical data
| EAN | 4003773034940 |
|---|---|
| Pliers | black atramentised |
| Head | polished |
| Handles | with comfort handles |
| Weight | 322 g |
| Dimensions | 200 x 55 x 24 mm |
| Standard | DIN ISO 5746 |
| REACH conformity | contains no SVHC |
| RoHS conformity | not applicable |
| Cutting capacity medium-hard wire (diameter) | Ø 3.8 mm |
| Cutting capacity hard wire (diameter) | Ø 2.5 mm |
| Cutting capacity Cu cable, multi-stranded | 16.0 mm² |
| Manufacturer | Knipex |
| Manufacturer Nr. | 03 02 200 |
| HS-Code | 82032000 |
| GPSR manufacturer information | KNIPEX-Werk Oberkamper Strasse 13 DE-42349 Wuppertal-Cronenberg www.knipex.de |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
| Height | 24 mm |
| Width | 55 mm |
| Colour | Black |
| Farbe | schwarz |
| Norm | DIN ISO 5746 |
| Overall length [mm] | 200 |
