Pipe wrench 90°, Swedish pattern, for pipes up to Ø 70 mm, 70 mm capacity, 560 mm - Knipex 83 10 020

On pipework close to a wall or in the corner of a shaft a straight pipe wrench can no longer be applied. The 90° angled jaws of the 83 10 020 grip pipes up to Ø 70 mm even where there is hardly any lateral space, and the 560 mm of leverage put the torque onto the pipe.

Benefits

• 90° angled jaws of Swedish pattern give access to fittings close to a wall, a ceiling or a floor.
• Jaws with double offset teeth, so the wrench pulls itself onto the pipe as the load increases.
• Teeth additionally induction-hardened to approx. 56 HRC, which keeps the grip reliable even on coated pipe.
• I-beam handle design for high stiffness at moderate weight.
• Captive adjusting nut, the width setting cannot be lost and can be corrected under load.
• Capacity of 70 mm, so the wrench also takes nuts with a width across flats of up to 70 mm.

Areas of use

Plumbing and heating, pipeline construction, plant assembly and maintenance. The angled design pays off wherever risers, manifolds or connections sit close to a surface and a straight pipe wrench can no longer be placed.

Standards and conformity

The pipe wrench is manufactured to DIN 5234. According to the manufacturer it contains no substances of very high concern under REACH. The RoHS directive does not apply to this hand tool.
