This special cartridge carries an angled knife blade 2.1 mm wide and 0.7 mm thick, developed for drag soldering multipads. The bevelled face carries enough solder to finish several leads in a single pass. It works with the T245 general purpose handle.
Soldering tip knife angled 2.1 mm for drag soldering with T245 - JBC C245728
JBC
Original product
Net price (excl. VAT)
€59.07
Item
WL74264
Manufacturer no.
C245728
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.C245728
Country of originSpain
ConditionNew
Article
WL74264
Frequently Bought Together
-
This Item:
€59.07
-
Soldering tip chisel high thermal 4.8 x 1.5 mm for T245 - JBC C245908
€27.51
-
Lötspitze abgeschrägt D 3,5 mm für T245 - JBC C245354E
€30.44
Total price
In drag soldering the blade geometry decides how much solder stays on the pads per pass. This cartridge was designed for multipads specifically: 2.1 mm blade width, 0.7 mm thickness and 10.1 mm usable length, angled and bevelled.
Benefits in detail
- Knife blade 2.1 x 0.7 mm, angled, developed for drag soldering multipads.
- The bevelled face acts as a solder reservoir and finishes a row of leads in one pass.
- The angled body keeps the handle out of the line of sight even at a shallow approach angle to the board.
- Cartridge of the C245 series, the widest JBC tip range with shapes from fine pitch to power soldering.
- Heater inside the tip, which gives instant heat up and fast recovery after each joint.
- According to the manufacturer, Long Life Tips with the Sleep and Hibernation functions reach several times the usual service life.
Technical data
| Model | C245728 |
|---|---|
| Tip series | C245 |
| Tip shape | bevelled, angled |
| Tip orientation | bevelled |
| Tip size | 3 x 10.1 mm |
| Tip length | 10.1 mm |
| Tip width | 2.1 mm |
| Tip thickness | 0.7 mm |
| Matching handpiece | T245 |
| ESD safe | no |
| Battery included | no |
| Weight | 0.009 kg |
| Packed dimensions | 110 x 12 x 12 mm |
| Sales unit | 1 piece |
| Content unit | 1 piece |
Applications
Drag soldering of multipads and QFP rows, rework on SMD assemblies, series soldering of closely spaced leads at the manual workstation.
Compatibility
Matched to the JBC T245 handles. C245 cartridges are not interchangeable with the C105 and C115 nano series.
