Cordless rework station B.IRON with B.NANO and B.TWEEZERS for C115, with 8.6 inch display - JBC BINP-5B

When replacing a 0402 resistor it is not power that decides, it is access to the part. The B.IRON Rework delivers 15 W per tool at 100 to 450 °C and works without a cable, so iron and heated tweezers move freely over the assembly.

Benefits in use

• Soldering iron and desoldering tweezers in one set, both fully compatible with the C115 cartridge range.
• The B.TWEEZERS nano tweezers manage up to 60 SMD rework operations per charge, the B.NANO tool around 120 joints.
• Selectable temperature range from 100 to 450 °C with ±3 % accuracy, 15 W peak power per tool.
• Battery operation takes the cable out of the field of view, which matters when removing small parts under a magnifier.
• The charging base charges each tool automatically as soon as it is placed in the holder, the energy saving mode is triggered by the cap.
• Quick cartridge changer, tip cleaner with brass wool, splash guard membrane and the HPTE0C9SA ESD tweezers are part of the set.
• A portable 8.6 inch display with the B.IRON app, Bluetooth 5.0 and a 5000 mAh battery is included.

Technical data

Applications

Rework and repair of the smallest SMD parts, removal of two terminal components with the heated nano tweezers, work under the microscope and mobile service without a socket at the point of work.

Compatibility and scope of delivery

• B.NANO nano tool for cartridges of the C115 range
• Heated B.TWEEZERS nano tweezers for cartridges of the C115 range
• Charging base with automatic charging when the tool is put down
• PDS portable display with 8.6 inches and the B.IRON app
• HPTE0C9SA high precision tweezers with ESD epoxy coating
• C115 cartridges are not part of the delivery

Standards and compliance

All B.IRON components comply with CE standards, the tools comply with ANSI/ESD S20.20. The tool itself is not grounded, so the user has to be grounded in an ESD compliant way.
