Cordless soldering station B-IRON Dual Nano 15 W with two B-NANO tools, no display - JBC BINN-5QB

Fine SMD work rarely fails because of the iron, it fails because of the cable and the distance to the joint. B-IRON Dual Nano runs on battery, the tool weighs 35 g and manages around 120 small SMD joints per charge. Thirty minutes in the cradle brings it back, and both tools can be controlled in real time.

Key benefits

• Two B-NANO tools included, both take the complete C115 cartridge range for 01005 to 0402 components.
• Working temperature from 100 to 450 °C with an accuracy of ± 3 percent using a reference cartridge.
• Li-ion battery with 7.4 V and 120 mAh inside the tool, charging time 30 minutes, charging starts automatically in the holder.
• Energy saving mode triggered by fitting the cap, plus a pen style clip for transport.
• Quick cartridge changer, brass wool tip cleaner and splash guard membrane are built into the station.
• HPTE0C9SA high precision tweezers with ESD epoxy coating are included.

Technical data

Applications

Repair and rework on densely populated boards, prototype building, work under a stereo microscope or magnifier lamp and service jobs away from a fixed bench.

Compatibility and scope of delivery

The cartridge type decides compatibility: the B-NANO tools accept C115 cartridges only. Delivery covers two B-NANO tools, the charging station, the HPTE0C9SA tweezers plus cartridge changer, tip cleaner and membrane. The portable 8.6 inch display with Bluetooth 5.0 and a 5000 mAh battery is not included and is ordered separately. A further tool can be added later.

Standards and compliance

The tool electronics meet ANSI/ESD S20.20 and all B-IRON components comply with CE standards. Important inside an EPA: the tool itself is not grounded, so the operator has to be grounded according to ESD rules. The manufacturer is JBC Soldering SL in Molins de Rei, Spain.
