Festo ESNU-12-25-P-A (19261) Standards-Based Cylind

Name: Festo ESNU-12-25-P-A (19261) Standards-Based Cylind
Brand: Festo
SKU: FES-19261
Price: 3918 EUR
Availability: InStock

€3,918.00

Excl. 19% VAT , excl. Shipping Cost

Article

FES-19261

Manufacturer Nr.

ESNU-12-25-P-A

Standards-Based Cylind

The product may differ from the illustration

Frequently Bought Together

This Item: Festo ESNU-12-25-P-A (19261) Standards-Based Cylind
€3,918.00
Excl. 19% VAT , excl. Shipping Cost
Festo DSNU-16-150-PPV-A (1908273) Standards-Based Cyli
€4,648.00
Excl. 19% VAT , excl. Shipping Cost
Festo DSNU-8-10-P-A (19177) Standards-Based Cylind
€2,991.00
Excl. 19% VAT , excl. Shipping Cost

Total price

Stroke [mm]	25
Piston diameter	12 mm
Piston rod thread	M6
Dampening	P: Elastic silencer rings / plates double-sided
installation position	arbitrary
Complies to standard	CETOP RP 52 P ISO 6432
Piston rod end	Male thread
Construction set up	Piston piston rod cylinder tube
Position detection	For proximity switch
Variants	One-sided piston rod
Operating pressure [bar]	1.5 to 10
Principle of operation	Pressing single action
Maritime classification	see Certificate
Operating medium	Compressed air to ISO 8573-1:2010 [7:4:4]
Information about operating and control medium	Oiled operation possible (required in further operations)
Corrosion resistant class KBK	2 - moderate corrosion stress
ambient temperature [°C]	-20 to 80
Impact energy at the end positions [J]	0,07
Theoretical force at 6 bar, flow [N]	61,0
Moving mass at 0 mm stroke [g]	18,5
Weight supplement per 10 mm stroke [g]	4,0
Base weight at 0 mm stroke [g]	75,0
Supplement moved mass per 10 mm stroke [g]	2
Fastening type	With Accessories
Pneumatic connection	M5
Material information	RoHs compliant
Cover material	Aluminium wrought alloy No-colour anodised
Seals material	NBR TPE-U(PU)
Piston rod material	High-alloyed stainless steels
Cylinder tube material	High-alloyed stainless steels

More Information
Manufacturer Nr.	ESNU-12-25-P-A
Manufacturer	Festo
EAN	4052568067175
Weight	0.085000
HS-Code	84123100
GPSR manufacturer information	Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
Article authenticity	Original product
Condition of article	New
