Festo valve for fast, reliable control of compressed-air direction and flow.
Toggle Lever Valve H-5/3-1/4 - Festo 4577
FESTO
Original product
Net price (excl. VAT)
€676.48
Item
FES-4577
Manufacturer no.
H-5/3-1/4
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.H-5/3-1/4
EAN4052568110574
Customs tariff number84812090
ConditionNew
Article
FES-4577
Frequently Bought Together
- This Item: €676.48
- Roller Lever Valve VMEF-R-M52-E-G18 - Festo 8047092 €106.25
- Stem Actuated Valve VMEF-S-M52-E-G14 - Festo 8031304 €100.99
Total price
Festo valve for fast, reliable control of compressed-air direction and flow. The key technical data of this genuine Festo article are listed below.
| Valve function | 5/3 closed |
| Actuation type | Manually |
| Normal nominal flow [l/min] | 680 |
| Operating pressure [bar] | 2 to 10 |
| Reset mode | Mechanical spring |
| Nominal width [mm] | 7 |
| Sealing principle | Soft |
| Control type | pilot operated |
| Flow direction | Not reversible |
| ambient temperature [°C] | -10 to 60 |
| Product weight [g] | 1.060 |
| Pneumatic connection 1 | G1/4 |
| Pneumatic connection 2 | G1/4 |
| Pneumatic connection 3 | G1/4 |
| Manufacturer Nr. | H-5/3-1/4 |
|---|---|
| Manufacturer | Festo |
| EAN | 4052568110574 |
| Weight | 1.100000 |
| HS-Code | 84812090 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Article authenticity | Original product |
| Condition of article | New |
| Temperature (max.) | 60 |
| Betriebsdruck max [bar] | 10.000000 |
| Pneumatic connection | G1/4 |
| Nennweite DN [mm] | 7 |
| Funktion | 5/3 closed |
| Durchfluss [l/min] | 680 |
| Position sensing | No |
| Actuation type | Manually |
