Pressure Gauge MA-27-160-M5-PSI - Festo 527405
Festo pneumatic component for industrial automation and compressed-air applications in proven quality.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Festo pneumatic component for industrial automation and compressed-air applications in proven quality. The key technical data of this genuine Festo article are listed below.
Technical data
| Nominal size pressure gauge | 27 |
|---|---|
| Construction set up | Pipe spring pressure gauge |
| Fastening type | pipe installation |
| Operating medium | Inert gases<br>Neutral liquids |
| Operating pressure [bar] | 0 to 11.0316 |
| Factor alternating strain | 0.66 |
| Measurement precision class | 4 |
| Protection category | IP43 |
| Medium temperature [°C] | 0 to 60 |
| ambient temperature [°C] | 0 to 60 |
| Material information | RoHs compliant |
| Connection position | Back side centred |
| Pneumatic connection | M5 |
| Stud material | Brass |
| Housing material | PA |
| Window material | PS |
| Housing colour | <span class="farbe" style="background-color:#000000"></span> black |
| Product weight [g] | 11 |
| Information about operating and control medium | No acetylene<br>No oxygen |
| Display range [psi] [psi] | 0 to 160 |
| From medium contacting materials | Brass |
| Weight | 0.014 kg |
| Manufacturer | Festo |
| Manufacturer Nr. | MA-27-160-M5-PSI |
| EAN | 4052568259556 |
| HS-Code | 90262040 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Condition of article | New |
| Article authenticity | Original product |
| Material | Polyamide (PA) |
| Gewinde | M5 |
| Design | Pipe spring pressure gauge |
| Series | MA |
| Betriebsdruck max [bar] | 11.03 |
| Protection class (IP) | IP43 |
| Temperature (max.) | 60 |
