Images are for illustration purposes only and may differ from the actual product. Some images have been generated or edited, in whole or in part, using artificial intelligence systems. The technical specifications in the product description are authoritative.
Festo pneumatic component for industrial automation and compressed-air applications in proven quality.
Angled Plug Socket MPPE-3-B - Festo 161839
FESTO
Original product
Net price (excl. VAT)
€77.03
Item
FES-161839
Manufacturer no.
MPPE-3-B
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.MPPE-3-B
EAN4052568012465
Customs tariff number85366990
ConditionNew
Article
FES-161839
Frequently Bought Together
-
This Item:
€77.03
-
Plug Socket NTSD-WD-9 - Festo 18527
€22.99
-
Plug NECU-S-M12G4-HX - Festo 562028
€14.71
Total price
Festo pneumatic component for industrial automation and compressed-air applications in proven quality. The key technical data of this genuine Festo article are listed below.
| Connection frequency | 500 |
| Fastening type | With Locking nut |
| installation position | arbitrary |
| Product weight [g] | 65 |
| Electrical connection | 8 pin<br>Angled socket<br>Solderable |
| Operating voltage range DC [V] | <= 60 V |
| Current carrying capacity [A] | 5 |
| Cable screwing | Pg9 |
| Permitted cable diameter [mm] | 6 to 8 |
| Connection cross-section [mm²] | 0,75 |
| Protection category | IP67 |
| ambient temperature [°C] | -30 to 95 |
| Housing material | PA |
| Housing colour | <span class="farbe" style="background-color:#000000"></span> black |
| Locking nut material | PA |
| Plug contacts material | Copper<br>Tin plated |
| Manufacturer Nr. | MPPE-3-B |
|---|---|
| Manufacturer | Festo |
| EAN | 4052568012465 |
| Weight | 0.043000 |
| HS-Code | 85366990 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Article authenticity | Original product |
| Condition of article | New |
| Temperature (max.) | 95 |
| Material | Polyamide (PA) |
| Protection rating | IP67 |
| Series | MPPE |
| Mounting position | arbitrary |
| Position sensing | No |
