Solenoid Coil VACC-S13-18-A1-1U - Festo 562890
Festo valve for fast, reliable control of compressed-air direction and flow.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Festo valve for fast, reliable control of compressed-air direction and flow. The key technical data of this genuine Festo article are listed below.
Technical data
| installation position | arbitrary |
|---|---|
| Power-on time | 100 % |
| Coil characteristic value | 24 V DC: 1,8 W<br>24 V AC: 40/65 Hz, power 1.8 VA |
| Permitted voltage oscillations | -15 % / +10 % |
| Protection category | IP65 |
| ambient temperature [°C] | -20 to 60 |
| Product weight [g] | 210 |
| Electrical connection | Wiring diagram Form A acc. to EN 175301-803<br>Plug<br>acc. to EN 175301-803 |
| Material information | LABS containing materials included<br>RoHs compliant |
| Switching position display | no |
| Solenoid material | PA<br>UP |
| Actuation type | Electrical |
| Insulation material class | H |
| Corrosion resistant class KBK | 4 - particularly severe corrosion stress |
| Weight | 0.25 kg |
| Manufacturer | Festo |
| Manufacturer Nr. | VACC-S13-18-A1-1U |
| EAN | 4052568210359 |
| HS-Code | 85059029 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Condition of article | New |
| Article authenticity | Original product |
| Corrosion resistance class CRC | 4 - particularly severe corrosion stress |
| Mounting position | arbitrary |
| Norm | DIN EN 175301-803 |
| Series | VACC |
| Protection class (IP) | IP65 |
| Temperature (max.) | 60 |
