Festo pneumatic component for industrial automation and compressed-air applications in proven quality.
Quick Exhaust Valve VBQF-D-G14-E - Festo 548003
FESTO Original product
Net price (excl. VAT)
€40.80
Item FES-548003
Manufacturer no. VBQF-D-G14-E
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.VBQF-D-G14-E
EAN4052568093174
Customs tariff number84812090
ConditionNew
Article
FES-548003
Frequently Bought Together
- This Item: €40.80
- Quick Exhaust Valve SE-3/8-B - Festo 9687 €51.28
- Quick Exhaust Valve SEU-3/8 - Festo 6755 €67.96
Total price
Festo pneumatic component for industrial automation and compressed-air applications in proven quality. The key technical data of this genuine Festo article are listed below.
| Valve function | Quick venting |
| Pneumatic connection 1 | G1/4 |
| Pneumatic connection 2 | G1/4 |
| Fastening type | Screwable |
| Normal flow Venting 6>0 bar [l/min] | 2.500 |
| Normal nominal flow venting 6->5 bar [l/min] | 960 |
| Operating pressure [bar] | 0.5 to 10 |
| ambient temperature [°C] | -20 to 80 |
| Housing material | Aluminium die casting<br>Zinc pressure cast |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Nominal width [mm] | 7 |
| installation position | arbitrary |
| Information about operating and control medium | Oiled operation possible (required in further operations) |
| Corrosion resistant class KBK | 1 - low corrosion stress |
| Medium temperature [°C] | -20 to 80 |
| Product weight [g] | 253,0 |
| Material information | RoHs compliant |
| Seals material | NBR |
| Normal nominal flow venting [l/min] | 1.500 |
| Pneumatic connection 3 | G1/4 |
| Manufacturer Nr. | VBQF-D-G14-E |
|---|---|
| Manufacturer | Festo |
| EAN | 4052568093174 |
| Weight | 0.260000 |
| HS-Code | 84812090 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Article authenticity | Original product |
| Condition of article | New |
| Temperature (max.) | 80 |
| Material | Aluminium |
| Betriebsdruck max [bar] | 10.000000 |
| Pneumatic connection | G1/4 |
| Series | VBQF |
| Nennweite DN [mm] | 7 |
| Dichtmaterial | NBR |
| Medium | Compressed air |
| Funktion | Quick exhaust |
| Corrosion resistance class CRC | 1 - low corrosion stress |
| Mounting position | arbitrary |
| Position sensing | No |
