Festo valve for fast, reliable control of compressed-air direction and flow.
Roller Lever Valve VMEF-R-M52-E-G18 - Festo 8047092
FESTO
Original product
Net price (excl. VAT)
€106.25
Item
FES-8047092
Manufacturer no.
VMEF-R-M52-E-G18
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.VMEF-R-M52-E-G18
EAN4052568294755
Customs tariff number84812090
ConditionNew
Article
FES-8047092
Frequently Bought Together
-
This Item:
€106.25
-
Hand Lever Valve VHER-P-H-B43U-G14 - Festo 3515573
€109.81
-
Pushbutton Valve F-3-M5 - Festo 4452
€108.19
Total price
Festo valve for fast, reliable control of compressed-air direction and flow. The key technical data of this genuine Festo article are listed below.
| Valve function | 5/2 monostable |
| Actuation type | Mechanical |
| Build.width [mm] | 20 |
| Normal nominal flow [l/min] | 750 |
| Betriebsdruck Mpa [MPa] | -0,095 bis 1 |
| Operating pressure [bar] | -0.95 to 10 |
| Construction set up | Piston pusher<br>Roller lever |
| Reset mode | Pneumatic spring |
| Nominal width [mm] | 5,2 |
| User information | Risk of trapping |
| Sealing principle | Soft |
| installation position | arbitrary |
| Control type | Direct |
| Flow direction | Reversible |
| Überdeckung | positive Überdeckung |
| Max. switching frequency [Hz] | 3 |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:-:-] |
| Information about operating and control medium | Oiled operation possible (required in further operations) |
| Corrosion resistant class KBK | 1 - low corrosion stress |
| Medium temperature [°C] | -10 to 60 |
| ambient temperature [°C] | -10 to 60 |
| actuating force [N] | 38,0 |
| Product weight [g] | 240 |
| Fastening type | With throughway bores |
| Pneumatic connection 1 | G1/8 |
| Pneumatic connection 2 | G1/8 |
| Pneumatic connection 3 | G1/8 |
| Material information | RoHs compliant |
| Seals material | NBR |
| Housing material | Aluminium wrought alloy, anodised |
| Pneumatic connection 4 | G1/8 |
| Pneumatic connection 5 | G1/8 |
| Cover material | PA reinforced |
| Max. stroke limit (hard) [mm] | 11,6 |
| Max. actuation speed for side actuation [m/s] | 1,4 |
| Cam angle [deg] | 30 |
| Information about ambient temperature | Heat influence on wear |
| Actuation attachment material | Zinc plated steel |
| Operating conditions | ISO 8573-1 |
|---|---|
| Manufacturer Nr. | VMEF-R-M52-E-G18 |
| Manufacturer | Festo |
| EAN | 4052568294755 |
| Weight | 0.240000 |
| HS-Code | 84812090 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Article authenticity | Original product |
| Condition of article | New |
| Temperature (max.) | 60 |
| Material | Aluminium |
| Betriebsdruck max [bar] | 10.000000 |
| Pneumatic connection | G1/8 |
| Series | VMEF |
| Nennweite DN [mm] | 5,2 |
| Dichtmaterial | NBR |
| Medium | Compressed air |
| Funktion | 5/2 monostable |
| Durchfluss [l/min] | 750 |
| Corrosion resistance class CRC | 1 - low corrosion stress |
| Mounting position | arbitrary |
| Design | Piston pusher, Roller lever |
| Position sensing | No |
| Actuation type | Mechanical |
