StepCut XL cable shears with step cut for fine stranded cables up to 120 mm², 225 mm - Knipex 95 18 225

Anyone cutting heavy copper and aluminium cables in grid and switchgear work reaches the force limit of compact cable shears very quickly. The KNIPEX StepCut XL 95 18 225 combines a high leverage joint, long handles and a stepped cutting edge and manages fine stranded cables up to 120 mm² at a tool length of 225 mm.

Benefits

• High leverage joint, long handles and optimised cutting edges give a noticeably easier cut than compact cable shears.
• Large capacity, solid copper or aluminium cables up to 35 mm², stranded cables up to 70 mm² and fine stranded cables up to 120 mm².
• Two cutting areas, the stepped main cutting edge always keeps small and large cables as close to the joint as possible, the front cutting edge separates very large cables step by step.
• Minimised handle opening for comfortable one-handed and two-handed operation even at large cable diameters.
• Bolted high leverage joint, smooth running and adjustable, combined with a slim head for better accessibility.
• Cutting edges additionally laser hardened to a cutting edge hardness of about 56 HRC, pinch guard for safe working.

Areas of use

Electrical installation, control cabinet and switchgear building, cable and grid construction, and service work on power distribution equipment. According to the manufacturer the shears are not suitable for steel reinforced cables such as ACSR.

Standards and conformity

For the handles the manufacturer states an insulating multi-component grip, VDE tested. No tool standard is named for this product. According to the manufacturer the shears contain no substances of very high concern under REACH, and the RoHS directive does not apply.
