ESD safety low shoe FLASH 5265 XP S3S, aluminium toe cap - Atlas 91600

Anyone on their feet all day feels every gram at the front of the shoe. Instead of steel the FLASH 5265 XP carries an alu-tec aluminium cap that takes the same 200 joules of impact energy and 15 kN of compression while weighing less, and it does not form the cold bridge a heavy steel cap creates in winter. For the ESD workplace the figure underneath counts: Atlas guarantees a person, shoe and floor resistance below 100 MOhm under the DIN EN 61340-5-1 measuring method.

What sets this model apart

• Class S3S to EN ISO 20345:2022, meaning a closed heel, antistatic construction, an energy absorbing heel area, resistance to water penetration and absorption, a cleated outsole and a non metallic penetration resistant insert tested with the thin 3.0 mm nail.
• alu-tec aluminium toe cap tested at 200 joules and 15 kN. An MPU overcap above it absorbs the wear on the toe of the shoe.
• XP penetration resistance made of aramid textile rather than a steel insert: metal free, light and flexible, so the foot keeps its natural torsion.
• XR-MPU sole technology with a cleated nitrile outsole and an MPU midsole, direct injected. The GRIP-SEGMENTS hold on wet, muddy and loose ground while the midsole cushions.
• SportLine upper of air permeable textile fibres together with the moisture regulating aktiv-X lining. The result is a shoe that is still dry after eight hours.
• Standard width 10 in the broad, foot friendly Atlas fit, released for insoles under DGUV rule 112-191.

Technical data

Areas of use

Assembly and production in electronics, workshop and maintenance, warehouse and dispatch in the ESD area, and work that leads outdoors, which is what the nitrile outsole is built for.

Standards and conformity

• EN ISO 20345:2022, safety class S3S, slip resistance SR
• DIN EN 61340-5-1, person, shoe and floor resistance below 100 MOhm
• EN ISO 20345 requires an antistatic range between 10 to the power of 5 ohms (100 kOhm) and 10 to the power of 9 ohms (1000 MOhm)
• PPE regulation (EU) 2016/425, risk category 2
• DGUV rule 112-191, suitable for insoles

Sizes

Available in EU sizes 36 to 49 in standard width 10. The sales unit is one pair.
