The product may differ from the illustration
The HD 2 lift-rotate unit turns the workpiece pallet into the required orientation within the TS 2plus transfer system while lifting it 90 mm above the conveyor level. The 90 mm lift version provides clearance for side-mounted components and keeps the pallet orientation constant in loop systems without curves.
Lift-rotate unit HD 2, ESD, b240 lT240, 180° rotation, 90 mm lift - Bosch Rexroth 3842525860
BOSCH REXROTH Original product
Net price (excl. VAT)
€4,907.61
Excl. 19% VAT , excl. Shipping Cost
Item BRR-3842525860
Manufacturer no. 3842525860
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.3842525860
Country of originGermany
Customs tariff number84313900
ConditionNew
Article
BRR-3842525860
Frequently Bought Together
- This Item: €4,907.61Excl. 19% VAT , excl. Shipping Cost
- Lift-Rotate Unit HD 2 ESD, 180° Rotation, 40 mm Lift, b160/lT160 - Bosch Rexroth 3842525848 €4,907.61Excl. 19% VAT , excl. Shipping Cost
- Lift-Rotate Unit HD 2, ESD, 180°, 240 mm Track Width, 90 mm Lift - Bosch Rexroth 3842525856 €4,907.61Excl. 19% VAT , excl. Shipping Cost
Total price
The HD 2 lift-rotate unit turns the workpiece pallet into the required orientation within the TS 2plus transfer system and lifts it above the conveyor level. In loop systems without curves it keeps the workpiece pallet orientation constant, so the front stays the front. Work operations on the HD 2 are permitted without additional external forces.
This 90 mm lift version is particularly suitable when components mounted at the side of the workpiece pallet, such as identification and data storage modules, need extra clearance.
- Turning angle 180° on the Z axis
- ESD version
- Supplied including fastening material
Technical data
| Type | Lift-rotate unit HD 2 |
| ESD | yes |
| Track width in direction of transport (b) | 240 mm |
| Length in direction of transport (lT) | 240 mm |
| Turning angle (DW) | 180° |
| Lift of WT over conveyor level (h) | 90 mm |
| Max. workpiece pallet total weight (mG) | 16 kg |
| Max. permitted total mass moment of inertia | 0.65 kgm² |
| Dimension c | 82 mm |
| Dimension d | 82 mm |
| Weight | 24 kg |
| Scope of delivery | incl. fastening material |
| Required accessories | Stop gate VE 2/..., M12x1 sensor (SN 4 mm) |
| Execution | TEC |
|---|---|
| Manufacturer Nr. | 3842525860 |
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 0.009900 |
| HS-Code | 84313900 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Article authenticity | Original product |
| Condition of article | New |
