Linear set LSA-A-10-DD by Bosch Rexroth, material number R103561020. The static load capacity is 380 N.
Linear set LSA-A-10-DD - Bosch Rexroth R103561020
BOSCH REXROTH
Original product
Net price (excl. VAT)
€37.66
Item
BRR-R103561020
Manufacturer no.
R103561020
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.R103561020
Country of originGermany
ConditionNew
Article
BRR-R103561020
Frequently Bought Together
-
This Item:
€37.66
-
Linear set LSFDR2-40-WV-900 - Bosch Rexroth R072354085
€703.79
-
Linear set LSHDR2T-25-WV-2000 - Bosch Rexroth R072252588
€732.86
Total price
Linear set LSA-A-10-DD by Bosch Rexroth, material number R103561020. The static load capacity is 380 N. Permissible values are up to 3 m/s travel speed and 150 m/s² acceleration. The weight is 0.11 kg.
Technical data
| Maximum permissible linear speed vmax | 3 m/s |
|---|---|
| Type | Linear set |
| Static load capacity C0 | 380 N |
| Series | Super A (with self-alignment feature) |
| Shaft radial clearance h6 | <prefix>+</prefix>36<suffix></suffix> |
| Breakaway force | 1 N |
| Maximum acceleration rate amax | 150 m/s² |
| Outer diameter D | 19 mm |
| Shaft diameter d | 10 mm |
| Linear guide type | Linear bushing and shaft |
| Format of linear bushings | – Closed |
| Dynamic load capacity C | 730 N |
| Friction force FR | 0.5 N |
| Permissible ambient temperature (min) | <prefix>-</prefix>10<suffix></suffix> °C |
| Permissible ambient temperature (max) | <prefix>+</prefix>80<suffix></suffix> °C |
| Weight | 0.11 kg |
| Permissible ambient temperature (min. ... max.) | -10 °C ... +80 °C |
| Manufacturer Nr. | R103561020 |
|---|---|
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 0.100000 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
