Cylinder Probe 63 mm, 2.3 kg, for Rp, Rg and Rv Resistance Testing, with Test Certificate - Desco 222008

Only a measurement shows whether a worksurface, mat or shelf in the EPA is really grounded. The Desco cylinder probe brings the defined 2.3 kg weight and 63 mm contact diameter that EN 61340-5 test methods assume, and gives repeatable readings when connected to a resistance meter.

Key benefits

• Three measurements: resistance to ground (Rg), point-to-point resistance (Rp) and volume resistance (Rv).
• Carbon-loaded rubber pads with Shore A hardness 55 ± 10 that leave no marks on the tested surface.
• Low internal resistance below 200 ohms that does not distort the result.
• Insulating jacket of approx. 1 x 10⁹ ohms and a shape that is easy to grip and place.
• Shrouded 4 mm socket and a cap that protects the pad when not in use.

Applications

Rg: place the probe on the surface, connect the meter to the probe and to ground, measure at 100 V. Rp: lay the material on an insulative surface such as clean glass and measure lengthwise and crosswise with two probes. Rv: sandwich the material between two probes, the lower one upside down. Typical for EPA qualification, audits to EN 61340-5-1 and incoming inspection of mats and flooring.
