Conductive L-shaped PCB rack, small, 25 slots x 2 mm, 208 x 272 x 93 mm - Desco 237195

Between two process steps, populated boards need a safe place to wait where they neither touch each other nor build up charge. The Desco 237195 small L-shaped PCB rack in black conductive polypropylene holds 25 boards in 2 mm slots and drains charge with a volume resistance of 1 x 10³ to less than 1 x 10⁵ ohms.

Key benefits

• Conductive polypropylene, Rv 1 x 10³ to less than 1 x 10⁵ ohms, suitable for CMOS-loaded assemblies
• 25 slots of 2 mm keep boards upright and separated
• L-shape with back wall supports boards about 25 % longer than the base depth
• Compact 208 x 272 x 93 mm footprint for use right on the bench
• Rated for operating temperatures up to 75 °C

Applications

As a buffer and staging point for boards at assembly, soldering and test stations, between placement and test or in the repair area. The manufacturer recommends using it at fully static-protected workstations with a grounded work surface. For larger boards, the large L-rack Desco 237200 offers 3 mm slots.

Standards

Resistance is measured per IEC 61340-2-3 and falls within the range that EN 61340-5-1 and the packaging standard IEC 61340-5-3 require for conductive packaging.
