ESD Circuit Board Shipper with Foam, 102 x 102 to 559 x 381 mm - Desco

Populated circuit boards and assemblies need to stay protected from electrostatic charge on their way to stores, customers or repair. This Desco Protektive Pak shipper is made of impregnated corrugated fibreboard: a conductive layer is buried inside the material and the surface is static dissipative. The shippers come in sizes from 102 x 102 x 54 mm to 559 x 381 x 76 mm. A foam insert holds the board in place and absorbs shock.

Key benefits

• Conductive layer inside the material instead of a coating, so the protection cannot rub or scratch off.
• Static dissipative surface for controlled charge decay without a hard discharge when touching the assembly.
• Foam insert cushions boards and assemblies against shock in transit.
• Economical for storage and shipping, reusable.
• Made from 100% recycled material and 100% recyclable.

Applications

Shipping and storing populated circuit boards, plug-in cards and assemblies, service returns, work-in-process storage and spare parts stores.

Standards

The shippers are part of the Desco Protektive Pak packaging range for ESD protected areas per ANSI/ESD S20.20. For transport outside an EPA, ANSI/ESD S541 calls for dissipative or conductive contact material and discharge shielding, and a closed shipper is the basis for that.
