724 Plus Workstation Monitor for 2 Operators and 1 Worksurface, Body Voltage Detection - Desco 770724

The SCS 724 Plus Workstation Monitor replaces daily wrist strap testing with uninterrupted monitoring: it continuously checks the path-to-ground of two operators including their safety resistors, and of one conductive or dissipative worksurface. Thanks to digital signal processing, a test voltage of 0.40 V on the operator is enough, and failures and intermittencies are flagged within 500 ms.

Key benefits

• True continuous rather than pulsed monitoring, unaffected by capacitance variations
• Low 0.40 V test voltage protects sensitive components
• Alarms on dangerous operator body voltage
• Alarms if the operator remote is intentionally disconnected
• Very compact at 0.85 x 2.4 x 2.6 in, with mounting tabs
• Dedicated monitor ground cord for ESD ground, AC equipment ground or auxiliary ground

Applications

Workstations with one or two operators in assembly, repair and test of sensitive assemblies. A second workstation can be connected with the 770733 operator remote.

Standards

Meets ANSI/ESD S20.20 in accordance with ESD TR1.0-01-01. Per ANSI/ESD S1.1, daily wrist strap testing may be omitted when continuous monitoring is used.
