USB Digital Microscope 5 MP 10-220x with Polarizer and AMR - Dino-Lite AM7515MZT

When findings have to be evidenced, the Dino-Lite AM7515MZT photographs and measures directly on the part.

What it does for you

• A 5 MP sensor and a 10-220x magnification range, so overview and detail come from the same device.
• The built-in polarizer suppresses reflections on metal, glass, plastic and circuit boards.
• AMR reads the set magnification automatically, so measurements stay correct without recalibrating.
• Flexible LED Control switches individual LED segments to take out cast shadows and hot spots.
• ESD safe housing for use at EPA workstations to IEC 61340-5-1.
• The MicroTouch trigger on the housing captures the image without shaking the camera.
• Wireless ready: with the WF-10 adapter the microscope runs cable free on tablet and phone.

Magnification, working distance and field of view

Values without front cap, as published by the manufacturer.

Typical uses

• Electronics manufacturing and repair: solder joints, BGA edges, tracks, placement errors.
• Quality control and incoming inspection: surface defects, burrs, coatings, dimensional checks.
• Materials testing: fracture surfaces, welds, corrosion, microstructure.
• Print and textiles: halftone dots, fibre orientation, ink build-up.
