i-Tool Pico MK2 Soldering Iron, 80 W - Ersa 0135CDK
Ultra-light, powerful i-Tool PICO MK2 soldering iron with 80 W for the i-CON PICO MK2 station. Fast tip changes via the Tip'N'Turn bayonet lock and cost-effective 142 series permanent tips.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Ersa i-Tool PICO MK2 is an ultra-light and powerful soldering iron for the i-CON PICO MK2 soldering station. It uses the same outstanding heating technology as the larger models in the Ersa i-Tool family and ships with a 1.6 mm chisel-shaped soldering tip.
The integrated Tip'N'Turn bayonet lock allows quick and easy tip changes and delivers a 20-25 % performance improvement compared with a screw connection. A wide range of cost-effective 142 series permanent soldering tips is available.
Technical data
| Rated power | 80 watts |
|---|---|
| Voltage | 16.50 volts |
| Max. tip temperature | 450 °C |
| Heat-up time | 9.00 sec. |
| Operating mode | station-based |
| Tip series | 142 |
| Soldering/desoldering tip | Series 0142CDLF16 |
| Tip shape | chisel-shaped |
| Tip type | straight |
| Tip diameter/width | 1.60 mm |
| Tip coating | permanent soldering tip |
| Replacement heater | 014100J |
| Antistatic design | Yes |
| RoHS compliant | Yes |
| Weight | 0.14 kg |
| Manufacturer | Ersa |
| Manufacturer Nr. | 0135CDK |
| EAN | 4003008153606 |
| GPSR manufacturer information | Ersa GmbH, Leonhard-Karl-Straße 24, DE-97877 Wertheim, www.kurtzersa.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
| Ausführung | gerade |
| Certification | RoHS 2011/65/EU |
| Power (W) | 80 W |
| Tip diameter/width [mm] | 1.6 |
| Soldering tip coating | Dauerlötspitze |
| Soldering tip shape | meißelförmig |
| Heat-up time [s] | 9 |
| Operating voltage | 16.5 V |
| Series | 142 |
| Temperature range | 150-450 °C |
| Temperature (max.) | up to 450 °C |
