FT-45 crimp tool for RJ-45 feed-thru modular plugs, trims wires flush - IDEAL 30-495
Compact FT-45 crimp tool for terminating RJ-45 feed-thru modular plugs. While crimping, it trims the fed-through conductors flush with the front of the plug. Designed for installers and technicians who terminate RJ-45 connectors on a regular basis.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
When you terminate patch cords and network drops every day, cutting each wire to an exact length is what slows you down. The FT-45 crimps feed-thru plugs, where the conductors pass through the front of the plug, and trims them flush with the plug face in the same stroke. At only 291 g it fits easily into any tool bag.
Benefits
- Crimps and trims the conductors flush in one operation, no separate trimming step
- Wiring order can be checked in the open plug before crimping, which reduces faulty terminations
- According to the instructions suitable for unshielded and shielded modular plugs
- Compact design with a net weight of 291 g for work on site
- Simple handling: place the assembly in the tool and squeeze the handle closed
Applications
- Termination of Cat5e and Cat6 network cables with feed-thru plugs
- Structured cabling, network outlets and patch panels in control cabinet building
- Maintenance and extension of networks in production and offices
Usage notes
- Unshielded plugs: remove 25-38 mm of jacket and remove the centre spline on Cat6 cable.
- Shielded plugs: remove 25-40 mm of jacket, keep the foil intact and fold it back over the jacket base.
- Untwist pairs to the jacket base, align in order, trim the ends flat and verify the wiring order before crimping.
Technical data
| Manufacturer part no. | 30-495 |
|---|---|
| EAN | 0783250787494 |
| Sales unit | 1 piece |
| Net weight | 291 g |
| Product line | FT-45, Datacomm Tools |
| Plug type | RJ-45 feed-thru modular plugs, unshielded and shielded |
| Function | Crimping and flush trimming of conductors |
| Jacket removal per instructions | 25-38 mm (unshielded), 25-40 mm (shielded) |
| Weight | 0.361 kg |
| Manufacturer | Ideal |
| Manufacturer Nr. | 30-495 |
| HS-Code | 82055980 |
| GPSR manufacturer information | IDEAL Industries International BV Franciscusweg 267 NL-1216 Hilversum www.idealind.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Taiwan |
