Counting Scale 6 kg / 15 kg Readability 0,002 kg / 0,005 kg - KERN IFS 10K-3M

The KERN IFS 10K-3M counts identical parts quickly and reliably instead of tallying them one by one, with a weighing range up to 15 kg and 0,002 kg readability. A numeric keypad and three separate displays turn reference sampling, piece counting and stocktaking into routine.

Benefits

• High counting resolution: up to 75.000 points for reliable piece-count determination.
• Convenient numeric keypad: direct entry of tare, reference and limit values on the ergonomic indicator.
• Three clear displays: weight, reference weight and total piece count visible at the same time.
• Automatic reference optimization: gradually refines the average piece weight for more accurate counting.
• Multi-range scale: switches automatically between 6 kg at 0,002 kg and 15 kg at 0,005 kg.
• Optionally verifiable (class III, e = 0,002 kg): for legal-for-trade use.

Technical data

• Weighing range (Max): 6 kg; 15 kg
• Readability (d): 0,002 kg; 0,005 kg
• Verification value (e): 0,002 kg; 0,005 kg
• Accuracy class: III
• Minimum capacity (Min): 0,04 kg; 0,1 kg
• Repeatability: 0,002 kg; 0,005 kg
• Linearity: ± 0,002 kg; 0,005 kg
• Smallest piece weight (laboratory conditions): 200 mg
• Smallest piece weight (normal conditions): 2 g
• Weighing system: Strain gauge
• Stabilization time: 2 s
• Weighing plate (W×D): 300×240 mm
• Display digit height: 16,5 mm
• Interfaces: RS-232 as standard
• Operating temperature: -10 °C to 40 °C
• Net weight: 4,8 kg

Applications

Typical uses of the KERN IFS 10K-3M include plastics processing, warehouse logistics, shipping, counting applications as well as order picking and stocktaking.

Compliance and origin

EAN 4045761150997, customs tariff code 84238129, country of origin China. For legal-for-trade use, the KERN IFS 10K-3M is optionally available in accuracy class III.
