Counting Scale 3 kg / 6 kg Readability 0,001 kg / 0,002 kg - KERN IFS 6K-3M

The KERN IFS 6K-3M counts and weighs in a single step: the industrial counting scale resolves up to 60,000 points and recognises quantities from a part weight of 1 g under normal conditions. Its 3 kg to 6 kg weighing range switches automatically to the matching readability as the load increases.

Benefits

• Verifiable, class III (e = 0,001 kg; 0,002 kg): legally compliant weighing and counting in trade.
• Two weighing ranges: 3 kg at 0,001 kg and 6 kg at 0,002 kg, switching automatically under load.
• Counting resolution up to 60,000 points: accurate quantities thanks to manual reference optimisation of the part weight.
• Convenient operation: numeric keypad and three separate displays for weight, reference and piece count.
• Built for industry: RS-232 as standard, protective work cover for the terminal included.

Technical data

• Weighing range (Max): 3 kg; 6 kg
• Readability (d): 0,001 kg; 0,002 kg
• Verification interval (e): 0,001 kg; 0,002 kg
• Accuracy class: III
• Minimum load (Min): 0,02 kg; 0,04 kg
• Repeatability: 0,001 kg; 0,002 kg
• Linearity: ± 0,001 kg; 0,002 kg
• Smallest part weight (normal conditions): 1 g
• Weighing surface (W×D): 300×240 mm
• Display digit height: 16,5 mm
• Interfaces: RS-232 as standard
• Operating temperature: -10 °C to 40 °C
• Net weight: 5,0 kg

Applications

Designed for plastics processing, warehouse logistics and dispatch, as well as counting tasks in order picking and stocktaking.

Compliance and origin

EAN 4045761151048, customs code 84238129, country of origin China.
