Counting Scale 6 kg / 15 kg Readability 0,002 kg / 0,005 kg - KERN IFS 10K-3LM

The KERN IFS 10K-3LM counts identical parts quickly and reliably instead of tallying them one by one, with a weighing range up to 15 kg and 0,002 kg readability. A numeric keypad and three separate displays turn reference sampling, piece counting and stocktaking into routine.

Benefits

• High counting resolution: up to 75.000 points for reliable piece-count determination.
• Convenient numeric keypad: direct entry of tare, reference and limit values on the ergonomic indicator.
• Three clear displays: weight, reference weight and total piece count visible at the same time.
• Automatic reference optimization: gradually refines the average piece weight for more accurate counting.
• Multi-range scale: switches automatically between 6 kg at 0,002 kg and 15 kg at 0,005 kg.
• Optionally verifiable (class III, e = 0,002 kg): for legal-for-trade use.

Technical data

• Weighing range (Max): 6 kg; 15 kg
• Readability (d): 0,002 kg; 0,005 kg
• Verification value (e): 0,002 kg; 0,005 kg
• Accuracy class: III
• Minimum capacity (Min): 0,04 kg; 0,1 kg
• Repeatability: 0,002 kg; 0,005 kg
• Linearity: ± 0,002 kg; 0,005 kg
• Smallest piece weight (laboratory conditions): 200 mg
• Smallest piece weight (normal conditions): 2 g
• Weighing system: Strain gauge
• Stabilization time: 2 s
• Weighing plate (W×D): 400×300 mm
• Display digit height: 16,5 mm
• Interfaces: RS-232 as standard
• Operating temperature: -10 °C to 40 °C
• Net weight: 7 kg

Applications

Typical uses of the KERN IFS 10K-3LM include plastics processing, warehouse logistics, shipping, counting applications as well as order picking and stocktaking.

Compliance and origin

EAN 4045761150980, customs tariff code 84238129, country of origin China. For legal-for-trade use, the KERN IFS 10K-3LM is optionally available in accuracy class III.
