UNILED SL workplace light 1045 mm micro-prism, 5700K 48W 24V DC - LED2WORK 110914-23

For single workstations, assembly lines and machines without coolant or chip spray, the UNILED SL LED system and workplace light provides high light diffusion of 7596 lm through its micro-prism cover over a 1045 mm length.

Your benefits

• Micro-prism cover for enhanced light diffusion and even light distribution.
• Daylight white at 5700 K with Ra >85 colour rendering for fatigue-free work.
• 7596 lm from only ~48 W, about 155 lm/W luminous efficacy.
• Aluminium and plastic housing with integrated mounting brackets.
• 24V DC extra-low voltage with M12 connector and ETL listing.
• Service life >100,000 h (L80/B10) for long maintenance intervals.

Technical data

• Model: UNILED SL DC
• Power: ~48 W
• Luminous flux: 7596 lm
• Light colour: 5700K 3-step MacAdam
• Colour rendering (Ra): >85
• Beam angle: 100°
• Supply voltage: 24V DC ± 10%
• Connection: M12 A-coded
• Protection rating (IP): IP50
• Protection class: III
• Operating temperature: -10 °C to +60 °C
• Service life: >100,000 h (L80/B10)
• Housing material: aluminium
• Cover material: micro-prism plastic
• Dimensions (H x W): 35 mm x 85 mm
• Length: 1045 mm
• Weight: 1720 g
• Risk group (DIN EN 62471): exempt group
• Certifications: CE, UKCA, ETL Listed (5003529)
• Made in: Germany

Applications

Suited to single workstations, assembly lines and machines without coolant or chip spray. Dimming is optionally available via accessories.
