UNILED SL workplace light 295 mm, 12W, 100°, IP50, 24V DC - LED2WORK 110914-11

Images are examples, some edited with AI. The technical data are authoritative. AI notice

UNILED SL workplace light 295 mm, 12W, 100°, IP50, 24V DC - LED2WORK 110914-11

Name: UNILED SL workplace light 295 mm, 12W, 100°, IP50, 24V DC - LED2WORK 110914-11
Brand: LED2WORK
SKU: L2W-110914-11
Price: 103.93 EUR
Availability: InStock

LED2WORK ✓ Original product Brand new Made in Germany

The UNILED SL is an ergonomic 295 mm LED system light delivering 1899 lm at 12 W for system workstations. Its opal-white glare control gives homogeneous, glare-free daylight, and the 24V DC supply connects via M12 A-coded.

Net

€103.93

excl. VAT

Item L2W-110914-11

Manufacturer no. 110914-11

Question about this item

Datasheet (PDF) User manual 5 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

For glare-free, motivating work light at inspection, single and assembly workstations, the 295 mm UNILED SL delivers 1899 lm at just 12 W. Its opal-white glare control provides homogeneous, shadow- and glare-free illumination.

Your benefits

Glare-free light: opal-white glare control for homogeneous, shadow-free illumination.
High efficiency: 1899 lm from 12 W, around 155 lm/W.
Good colour rendering: Ra > 85 at 5700K daylight white.
Long service life: over 100,000 h (L80/B10), low maintenance.
Easy mounting: integrated fixing tabs on the aluminium housing.
24V system light: ideal for system workstations, with ETL Listed certificate.

Applications

For lighting inspection stations, single workstations and assembly stations wherever a 24V system light with UL/CSA requirement and glare-free daylight is needed. Optionally dimmable via accessories.

Technical data

Model	UNILED SL DC
Type	LED system and workplace light
Light source	SMD LED
Power	~12 W
Luminous flux	1899 lm
Luminous efficacy	~155 lm/W
Light distribution	direct
Light colour	5700K 3-step MacAdam
Colour rendering (Ra)	> 85
Supply voltage	24V DC ± 10%
Connection	M12 A-coded
Protection rating (IP)	IP50
Protection class	III
Glare control	opal white
Beam angle	100°
Operating temperature	-10 °C to +60 °C
Service life	> 100,000 h (L80/B10)
Housing material	aluminium
Cover material	matt plastic
Dimensions	295 mm x 85 mm x 35 mm
Weight	550 g
Risk group (DIN EN 62471)	exempt group
Certifications	CE, UKCA, ETL Listed (5003529)
Made in	Germany
Manufacturer	LED2WORK
Manufacturer Nr.	110914-11
HS-Code	94054239
GPSR manufacturer information	LED2WORK GmbH, Stuttgarter Straße 13 A, 75179 Pforzheim www.led2work.com
Condition of article	New
Article authenticity	Original product
Country of Manufacture	Germany
ESD version	TEC
Norm	DIN EN 62471
Control and dimming	Dimmable
Luminous flux (lumen)	1899 lm
Power (W)	12 W
Colour temperature	5700K
Operating voltage	24 V
Protection class (IP)	IP50
