UNILED SL workplace light 1545 mm opal white, 5700K 72W 24V DC - LED2WORK 110914-14

Where inspection, single or assembly workstations need even, motivating daylight, the UNILED SL LED system and workplace light delivers 11394 lm of homogeneous, shadow-free and glare-free area lighting over a 1545 mm length.

Your benefits

• Glare-free daylight white at 5700 K with Ra >85 colour rendering for fatigue-free vision.
• Opal-white glare control gives homogeneous, shadow-free illumination without harsh reflections.
• 11394 lm from only ~72 W, about 155 lm/W luminous efficacy.
• Aluminium and plastic housing with integrated mounting brackets for quick installation.
• 24V DC extra-low voltage with M12 connector and ETL listing for system workstations.
• Service life >100,000 h (L80/B10) for long maintenance intervals.

Technical data

• Model: UNILED SL DC
• Power: ~72 W
• Luminous flux: 11394 lm
• Light colour: 5700K 3-step MacAdam
• Colour rendering (Ra): >85
• Beam angle: 100°
• Supply voltage: 24V DC ± 10%
• Connection: M12 A-coded
• Protection rating (IP): IP50
• Protection class: III
• Operating temperature: -10 °C to +60 °C
• Service life: >100,000 h (L80/B10)
• Housing material: aluminium
• Cover material: matt plastic, opal white
• Dimensions (H x W): 35 mm x 85 mm
• Length: 1545 mm
• Weight: 2850 g
• Risk group (DIN EN 62471): exempt group
• Certifications: CE, UKCA, ETL Listed (5003529)
• Made in: Germany

Applications

Ideal for lighting inspection benches, single workstations and assembly stations, and anywhere a 24V system light with ETL certification is required. Dimming is optionally available via accessories.
