UNILED SL workplace light 295 mm micro-prism, 5700K 12W 24V DC - LED2WORK 110914-21
UNILED SL LED system and workplace light, 295 mm, with micro-prism cover for high light diffusion and even distribution. Delivers 1899 lm at ~12 W in 5700K, IP50, 24V DC with M12 connection. ETL listed and made in Germany.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
For single workstations, assembly lines and machines without coolant or chip spray, the UNILED SL LED system and workplace light provides high light diffusion of 1899 lm through its micro-prism cover over a 295 mm length.
Your benefits
- Micro-prism cover for enhanced light diffusion and even light distribution.
- Daylight white at 5700 K with Ra >85 colour rendering for fatigue-free work.
- 1899 lm from only ~12 W, about 155 lm/W luminous efficacy.
- Aluminium and plastic housing with integrated mounting brackets.
- 24V DC extra-low voltage with M12 connector and ETL listing.
- Service life >100,000 h (L80/B10) for long maintenance intervals.
Applications
Suited to single workstations, assembly lines and machines without coolant or chip spray. Dimming is optionally available via accessories.
Technical data
| Model | UNILED SL DC |
|---|---|
| Power | ~12 W |
| Luminous flux | 1899 lm |
| Light colour | 5700K 3-step MacAdam |
| Colour rendering (Ra) | >85 |
| Beam angle | 100° |
| Supply voltage | 24V DC ± 10% |
| Connection | M12 A-coded |
| Protection rating (IP) | IP50 |
| Protection class | III |
| Operating temperature | -10 °C to +60 °C |
| Service life | >100,000 h (L80/B10) |
| Housing material | aluminium |
| Cover material | micro-prism plastic |
| Dimensions (H x W) | 35 mm x 85 mm |
| Length | 295 mm |
| Weight | 550 g |
| Risk group (DIN EN 62471) | exempt group |
| Certifications | CE, UKCA, ETL Listed (5003529) |
| Made in | Germany |
| Manufacturer | LED2WORK |
| Manufacturer Nr. | 110914-21 |
| HS-Code | 94054239 |
| GPSR manufacturer information | LED2WORK GmbH, Stuttgarter Straße 13 A, 75179 Pforzheim www.led2work.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
| Norm | DIN EN 62471 |
| Luminous flux (lumen) | 1899 lm |
| Power (W) | 12 W |
| Colour temperature | 5700K |
| Operating voltage | 24 V |
| Protection class (IP) | IP50 |
