PROFILED DC LED profile light 500 mm, 11 W, 100°, 5700K, M12 A-coded, 24V DC - LED2WORK 150314-01

The PROFILED DC is a versatile LED profile light with a rear T-slot fixing that lights workshops, logistics areas and system workstations evenly. The light-diffusing micro-prism cover provides low-shadow lighting of production, assembly and packaging at 1670 lm.

Key benefits

• Even area lighting with 1670 lm at around 11 W
• Micro-prism cover for low-shadow lighting, 100° beam angle
• Neutral white light 5700K, colour rendering Ra above 85
• Rugged aluminium housing with rear T-slot fixing
• Connection via M12 A-coded for 24V DC
• Long service life of more than 100,000 h (L80/B10)

Technical data

• Model: PROFILED DC
• Design: profile light with rear T-slot
• Light source: SMD LED
• Power: approx. 11 W
• Luminous flux: 1670 lm
• Luminous efficacy: approx. 155 lm/W
• Light colour: 5700K 3-step MacAdam
• Colour rendering (Ra): above 85
• Supply voltage: 24V DC plus/minus 10%
• Connection: M12 A-coded
• Protection rating: IP40
• Protection class: III
• Glare control: micro-prisms
• Beam angle: 100°
• Operating temperature: -10 °C to +60 °C
• Service life: over 100,000 h (L80/B10)
• Housing material: aluminium
• Cover material: plastic
• Dimensions: length 500 mm, height 65 mm x width 45 mm
• Weight: 1060 g
• Risk group (DIN EN 62471): exempt group
• Certifications: CE, UKCA, ETL Listed (5003529)
• Made in: Germany

Applications

Universal and system light for workshops, logistics areas, system workstations and production, assembly and packaging.

Note

Dimming optional via accessory, mounting hardware available as an option.
