PROFILED AC LED profile light 500 mm dimmable, 14 W, 100°, 5700K, 3 m mains cable, 120-277V AC - LED2WORK 150314-04

The PROFILED AC with internal dimmer is a versatile LED profile light with an integrated driver and rear T-slot fixing. It runs from the 3 m connecting cable with mains plug, brightness can be adjusted internally and the micro-prism cover provides balanced, low-shadow lighting.

Key benefits

• Integrated driver and internal dimmer
• Direct operation on the 120-277V AC supply
• Even area lighting with 1670 lm, total power around 14 W
• Micro-prism cover for balanced, low-shadow lighting, 100°
• Neutral white light 5700K, colour rendering Ra above 85
• Rugged aluminium housing, 3 m connecting cable, service life over 100,000 h

Technical data

• Model: PROFILED AC
• Design: profile light with rear T-slot
• Light source: SMD LED
• Total power incl. driver: approx. 14 W
• Lamp power: approx. 11 W
• Luminous flux: 1670 lm
• Luminous efficacy: approx. 155 lm/W
• Light colour: 5700K 3-step MacAdam
• Colour rendering (Ra): above 85
• Supply voltage: 120-277V AC plus/minus 10%, 50-60 Hz
• Driver: integrated
• Connection: 3 m connecting cable with mains plug
• Protection rating: IP40
• Protection class: I
• Glare control: micro-prisms
• Beam angle: 100°
• Operating temperature: -10 °C to +45 °C
• Service life: over 100,000 h (L80/B10)
• Housing material: aluminium
• Cover material: plastic
• Dimensions: length 500 mm, height 65 mm x width 45 mm
• Weight: 1560 g
• Risk group (DIN EN 62471): exempt group
• Certifications: CE, UKCA
• Dimmable: internal dimmer
• Made in: Germany

Applications

Universal light with dimmer for workshops, logistics areas, system workstations and production, assembly and packaging with direct mains connection.

Note

Mounting hardware available as an option.
