PROFILED AC LED profile light 900 mm, 3340 lm, 5700K, 100°, Wieland GST18 - LED2WORK 150614-07
PROFILED AC LED profile light 900 mm, 3340 lm, 5700K, 100°, Wieland GST18 - LED2WORK 150614-07 PROFILED AC LED profile light 900 mm, 3340 lm, 5700K, 100°, Wieland GST18 - LED2WORK 150614-07 PROFILED AC LED profile light 900 mm, 3340 lm, 5700K, 100°, Wieland GST18 - LED2WORK 150614-07 PROFILED AC LED profile light 900 mm, 3340 lm, 5700K, 100°, Wieland GST18 - LED2WORK 150614-07 PROFILED AC LED profile light 900 mm, 3340 lm, 5700K, 100°, Wieland GST18 - LED2WORK 150614-07 PROFILED AC LED profile light 900 mm, 3340 lm, 5700K, 100°, Wieland GST18 - LED2WORK 150614-07

Images are examples, some edited with AI. The technical data are authoritative. AI notice

Profiled AC LED profile light 900 mm, 3340 lm, 5700K, 100°, Wieland GST18 - LED2WORK 150614-07

LED2WORK ✓ Original product Brand new Made in Germany

Sturdy LED profile light for workshops and system workstations, 900 mm long with 3340 lm luminous flux and an even 100° distribution. The rear T-slot allows quick mounting and the connection is made via Wieland GST18.

Net
€173.80
excl. VAT
Item L2W-150614-07
Manufacturer no. 150614-07
Save Compare
Question about this item
Datasheet (PDF) User manual 5 documents, all under Downloads
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The PROFILED AC lights workshops, logistics areas and system workstations evenly and with low shadowing. Over 900 mm it delivers 3340 lm at around ~24 W, while the microprism cover spreads the light softly across the work surface.

Benefits

  • Even area lighting from a 100° beam angle and microprism optics
  • Connection via Wieland GST18
  • Fast mounting via the rear T-slot profile
  • 3340 lm at around ~24 W, roughly 155 lm/W luminous efficacy
  • Long service life of over 100,000 h (L80/B10), maintenance-free
  • Sturdy aluminium housing, neutral white 5700K light with Ra above 85

Applications

Ideal for lighting workstations in production, assembly and packaging as well as workshops and logistics areas. Mounting accessories are available as an option.

Technical data

ModelPROFILED AC
Designprofile light with rear T-slot
Light sourceSMD LED
Total power incl. driver~24 W
Power~21 W
Luminous flux3340 lm
Luminous efficacy~155 lm/W
Light colour5700K 3-step MacAdam
Colour rendering (Ra)>85
Supply voltage120-277V AC ± 10%, 50-60 Hz
ConnectionWieland GST18
Protection rating (IP)IP40
Protection classI
Beam angle100°
Operating temperature-10 °C to +45 °C
Service life> 100,000 h (L80/B10)
Housing materialaluminium
Cover materialplastic
Dimensions900 mm x 65 mm x 45 mm
Weight1950 g
Risk group (DIN EN 62471)exempt group
CertificationsCE, UKCA
Made inGermany
ManufacturerLED2WORK
Manufacturer Nr.150614-07
HS-Code94054239
GPSR manufacturer informationLED2WORK GmbH, Stuttgarter Straße 13 A, 75179 Pforzheim www.led2work.com
Condition of articleNew
Article authenticityOriginal product
Country of ManufactureGermany
NormDIN EN 62471
Luminous flux (lumen)3340 lm
Power (W)24 W
Colour temperature5700K
Mounting typeT-slot / profile
Operating voltage120-277 V
Protection class (IP)IP40

Downloads

Datasheet

User Manual

Catalogue

Accessories

Show 3 more items

ESD version

Questions about this item

Any other question?

Send us the item number and your question. We clarify technical details directly with the manufacturer and usually reply on the next working day.
