PROFILED AC LED profile light 900 mm dimmable, 3340 lm, 5700K, 100°, Wieland GST18 - LED2WORK 150614-08

The PROFILED AC lights workshops, logistics areas and system workstations evenly and with low shadowing. Over 900 mm it delivers 3340 lm at around ~24 W, while the microprism cover spreads the light softly across the work surface.

Benefits

• Continuously adjustable via the internal dimmer
• Even area lighting from a 100° beam angle and microprism optics
• Connection via Wieland GST18
• Fast mounting via the rear T-slot profile
• 3340 lm at around ~24 W, roughly 155 lm/W luminous efficacy
• Long service life of over 100,000 h (L80/B10), maintenance-free
• Sturdy aluminium housing, neutral white 5700K light with Ra above 85

Technical data

• Model: PROFILED AC
• Design: profile light with rear T-slot
• Light source: SMD LED
• Total power incl. driver: ~24 W
• Power: ~21 W
• Luminous flux: 3340 lm
• Luminous efficacy: ~155 lm/W
• Light colour: 5700K 3-step MacAdam
• Colour rendering (Ra): >85
• Supply voltage: 120-277V AC ± 10%, 50-60 Hz
• Connection: Wieland GST18
• Dimmable: internal dimmer
• Protection rating (IP): IP40
• Protection class: I
• Beam angle: 100°
• Operating temperature: -10 °C to +45 °C
• Service life: > 100,000 h (L80/B10)
• Housing material: aluminium
• Cover material: plastic
• Dimensions: 900 mm x 65 mm x 45 mm
• Weight: 1950 g
• Risk group (DIN EN 62471): exempt group
• Certifications: CE, UKCA
• Made in: Germany

Applications

Ideal for lighting workstations in production, assembly and packaging as well as workshops and logistics areas. Mounting accessories are available as an option.
