TUBELED_40 II Integrated RGB-W LED recessed light 395 mm, signal function - LED2WORK 151190-01

The TUBELED_40 II Integrated RGB-W combines machine lighting and coloured signalling in one recessed light for standardised or prepared light wells. With a 395 mm x 74 mm bezel projecting just 3 mm, it delivers 1215 lm of white light at 5000K and signals via RGB LED chips by flashing or changing colour.

Your benefits

• Lighting and signalling with a single recessed light
• 1215 lm of white light at 5000K plus red, green and blue signalling
• Signal function by flashing or changing the light colour
• IP67/IP69K rating, resistant to oil and coolant and safe against flying chips
• Bezel projecting just 3 mm, CNC-suitable
• Long service life of over 100,000 h (L80/B10)

Technical data

• Model: TUBELED_40 II Integrated RGB-W
• Type: LED recessed light
• Light source: SMD RGB-W cluster LED
• Power white: ~9.5 W
• Luminous flux white: 1215 lm
• Luminous efficacy white: ~126 lm/W
• Power red: ~9 W, 240 lm
• Power green: ~2.5 W, 345 lm
• Power blue: ~9 W, 150 lm
• Light colour white: 5000K 3-step MacAdam
• Colour rendering white: Ra >80
• Beam angle: 100°
• Supply voltage: 24 V DC -10 %/+7 % (RGB), 24 V DC ±10 % (W)
• Connection: M12 A-coded
• Protection rating: IP67/IP69K
• Protection class: III
• Operating temperature: -30 °C to +60 °C
• Service life: > 100,000 h (L80/B10)
• Housing: aluminium
• Cover: safety glass, shatterproof
• Dimensions: 395 mm x 74 mm x 32 mm, bezel projecting 3 mm
• Weight: 700 g
• Risk group (DIN EN 62471): exempt group
• Certifications: CE, UKCA, ETL Listed (5003529), D mark
• Made in: Germany

Applications

For installation in light wells of machines and plant, to light working areas and at the same time signal status changes such as process end, fault or status change by colour.
