TUBELED_40 II RGB-W Power LED machine light 1540 mm, signal function - LED2WORK 118690-01

Name: TUBELED_40 II RGB-W Power LED machine light 1540 mm, signal function - LED2WORK 118690-01
Brand: LED2WORK
SKU: L2W-118690-01
Price: 800.10 EUR
Availability: InStock

LED2WORK ✓ Original product Brand new Made in Germany

LED hybrid luminaire for lighting and signalling in one unit. The Power variant delivers 7290 lm of daylight-white light plus coloured RGB signalling by flashing or colour change, slim surface-mount and rated IP67/IP69K.

Net

€800.10

excl. VAT

Item L2W-118690-01

Manufacturer no. 118690-01

Question about this item

Datasheet (PDF) User manual 5 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

The TUBELED_40 II RGB-W Power combines bright workplace lighting and coloured signalling in one slim surface-mounted machine light. The flux-optimised Power variant delivers 7290 lm of daylight white and signals status changes via RGB LED chips by flashing or changing the light colour.

Your benefits

Lighting and signalling with a single luminaire
7290 lm of white light plus red, green and blue signalling
Signal function by flashing or changing the light colour
IP67/IP69K rating, resistant to oil and coolant and safe against flying chips
Slim surface-mount at just 29 mm height, CNC-suitable
Long service life of over 100,000 h (L80/B10)

Applications

For lighting and simultaneously signalling status changes in the working areas of machines and plant, such as process end, fault or status change. Mounting accessories optional.

Technical data

Model	TUBELED_40 II RGB-W Power
Type	LED surface-mounted light
Light source	SMD RGB-W cluster LED
Power white	~57 W
Luminous flux white	7290 lm
Luminous efficacy white	~126 lm/W
Power red	~54 W, 1440 lm
Power green	~15 W, 2070 lm
Power blue	~54 W, 900 lm
Colour rendering white	Ra >80
Beam angle	100°
Supply voltage	24 V DC -10 %/+7 % (RGB), 24 V DC ±10 % (W)
Connection	M12 A-coded, 5-pin
Protection rating	IP67/IP69K
Protection class	III
Operating temperature	-30 °C to +60 °C
Service life	> 100,000 h (L80/B10)
Housing	aluminium
Cover	safety glass, shatterproof
Dimensions	1540 mm x 40 mm x 29 mm
Weight	2020 g
Risk group (DIN EN 62471)	exempt group
Certifications	CE, UKCA, ETL Listed (5003529), D mark
Made in	Germany
Manufacturer	LED2WORK
Manufacturer Nr.	118690-01
HS-Code	94054239
GPSR manufacturer information	LED2WORK GmbH, Stuttgarter Straße 13 A, 75179 Pforzheim www.led2work.com
Condition of article	New
Article authenticity	Original product
Country of Manufacture	Germany
Norm	DIN EN 62471
Luminous flux (lumen)	7290 lm
Power (W)	57 W
Colour rendering (Ra)	Ra 80
Mounting type	Surface-mounted
Operating voltage	24 V
Protection class (IP)	IP69K
