VARILED II Power LED surface-mounted machine light 125 mm, 4 W, IP67, 100°, 24V DC - LED2WORK 157010-01

Images are examples, some edited with AI. The technical data are authoritative. AI notice

VARILED II Power LED surface-mounted machine light 125 mm, 4 W, IP67, 100°, 24V DC - LED2WORK 157010-01

Name: VARILED II Power LED surface-mounted machine light 125 mm, 4 W, IP67, 100°, 24V DC - LED2WORK 157010-01
Brand: LED2WORK
SKU: L2W-157010-01
Price: 60.63 EUR
Availability: InStock

LED2WORK ✓ Original product Brand new Made in Germany

Slim LED surface-mounted light (13.7 mm high) for machines with tight space. Delivers 633 lm at 4 W (155 lm/W, 5700K). Aluminium and safety-glass housing, IP67, vibration- and shock-resistant, M8 connection, 24V DC.

Net

€60.63

excl. VAT

Item L2W-157010-01

Manufacturer no. 157010-01

Question about this item

Datasheet (PDF) User manual 5 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

The VARILED II Power is a slim LED surface-mounted light less than 15 mm high, for machines and systems with tight installation space. Over 125 mm it delivers 633 lm at 4 W and a luminous efficacy of 155 lm/W, in daylight-white 5700K.

Key benefits

Extremely low 13.7 mm height fits cramped machine installations
High efficiency of 155 lm/W, 633 lm from only 4 W
Sturdy housing of aluminium and toughened safety glass, IP67 dust-tight and temporarily submersible
High mechanical resilience: vibration-resistant (10 to 55 Hz, amplitude 0.35 mm) and shock-resistant up to 50 g
Wide operating temperature range of -30 °C to +60 °C
Long service life over 100,000 h (L80/B10), connection via M8 connector (A-coded), 24V DC

Applications

Machine interior lighting, machine tools, packaging and special-purpose machines and any industrial environment with limited space that needs dust-, splash- and vibration-resistant illumination.

Technical data

Model	VARILED II Power
Light source	SMD LED
Power	4 W
Luminous flux	633 lm
Luminous efficacy	155 lm/W
Light colour	5700K 3-step MacAdam
Colour rendering (Ra)	>85
Supply voltage	24V DC ± 10%
Control gear	external
Connection	M8 A-coded, 3-pin
Protection rating	IP67
Protection class	III
Operating temperature	-30 °C to +60 °C
Storage temperature	-30 °C to +80 °C
Service life	> 100,000 h (L80/B10)
Vibration resistance	10 to 55 Hz (amplitude 0.35 mm)
Shock resistance	up to 50 g
Housing	aluminium and glass
Dimensions (H x W)	13.7 mm x 40.2 mm
Length	125 mm
Weight	150 g
Risk group (DIN EN 62471)	exempt group
Certifications	CE, UKCA, ETL Listed (5003529)
Dimmable	optional via accessory and M12/M8 adapter 200200-25
Made in	Germany
Manufacturer	LED2WORK
Manufacturer Nr.	157010-01
HS-Code	94054239
GPSR manufacturer information	LED2WORK GmbH, Stuttgarter Straße 13 A, 75179 Pforzheim www.led2work.com
Condition of article	New
Article authenticity	Original product
Country of Manufacture	Germany
Norm	DIN EN 62471
Control and dimming	Dimmable
Luminous flux (lumen)	633 lm
Power (W)	4 W
Colour temperature	5700K
Beam angle	100°
Mounting type	Surface-mounted
Operating voltage	24 V
Protection class (IP)	IP67
