TUBELED_40 II Basic-Line Machine Light 280 mm, 5.7 W, 5700 K, 100° - LED2WORK 118110-06
Rugged LED machine light for tasks with moderate output needs. Over a 280 mm length it delivers 881 lm at just 5.7 W, with IP67/IP69K protection and 4 mm safety glass for harsh machine environments.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
When a machine work area needs reliable illumination without demanding maximum output, the TUBELED_40 II Basic-Line is the right budget version. It keeps the design and durability of the proven standard model and delivers 881 lm at only 5.7 W across a 280 mm length.
Your benefits
- High efficiency of 155 lm/W keeps energy use low
- IP67/IP69K protection for wet and heavily soiled environments
- 4 mm safety glass (ESG) with diffuser for even, low-glare light
- Aluminium housing with a compact 29 mm build height
- Long service life of more than 60,000 h (L70/B50)
Applications
Suited to lighting work areas in machine tools, assembly cells and equipment where a rugged light with reduced output is required. Undervoltage (< 24 V DC) reduces the luminous flux.
Technical data
| Model | TUBELED_40 II Basic-Line |
|---|---|
| Design | LED surface-mounted machine light |
| Light source | SMD LED |
| Power | 5.7 W |
| Luminous flux | 881 lm |
| Luminous efficacy | 155 lm/W |
| Light colour | 5700 K 3-step MacAdam |
| Colour rendering (Ra) | >80 |
| Beam angle | 100° |
| Supply voltage | 24 V DC |
| Connection | M12 A-coded, 3-pin |
| Protection rating | IP67/IP69K |
| Protection class | III |
| Operating temperature | -20 °C to +50 °C |
| Service life | >60,000 h (L70/B50) |
| Housing | aluminium |
| Cover | safety glass, 4 mm |
| Dimensions | 280 mm x 40 mm x 29 mm |
| Weight | 400 g |
| Risk group (DIN EN 62471) | exempt group |
| Certifications | CE, UKCA |
| Made in | Germany |
| Manufacturer | LED2WORK |
| Manufacturer Nr. | 118110-06 |
| HS-Code | 94059900 |
| GPSR manufacturer information | LED2WORK GmbH, Stuttgarter Straße 13 A, 75179 Pforzheim www.led2work.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
| Norm | DIN EN 62471 |
| Luminous flux (lumen) | 881 lm |
| Power (W) | 5.7 W |
| Colour temperature | 5700K |
| Mounting type | Surface-mounted |
| Operating voltage | 24 V |
| Protection class (IP) | IP69K |
