MOT98 motor drive unit 230 V for Superform/AF and Superform/VP - Iteco 7915032

The Superform/AF works in two steps: first cut and U-bend, then preform the leads while the feed stands still. Done by hand this sequence is slow. With the 230 V version of the MOT98 motor drive it runs automatically and the machine reaches the catalogue rate of 7,000 components per hour.

Benefits in operation

• Designed specifically for Superform/AF and VP, that is for machines with an additional preforming stage.
• Infinitely variable speed control, so the cycle can be matched to the die assembly in use.
• Automatic operation instead of hand cranking keeps cut length, bend length and curl position constant across the batch.
• Emergency stop button and speed dial on the drive housing, no separate control cabinet needed.
• Foot switch Iteco 600023 can be connected, keeping both hands on the tape and the outfeed.

Technical data

Typical applications

Automating a Superform/AF for stand-off and lock-in preforms, series production with changing die assemblies, upgrading a manual AF or VP to motor operation.

Compatibility and scope of delivery

For Superform/AF (Iteco 7915095, 7915096, 7915097) and Superform/VP. According to the Iteco catalogue the motor unit is supplied only with the machine assembled. For Superform/A, AP, S, V and R the unit Iteco 7915030 applies instead. Matching accessories are the BR6 tape reel holder (Iteco 7915185) and the CS40 loose component feeder (Iteco 7915184). Made in Italy.
