ThermoFlo BGA Nozzle Rectangular 9 x 11 mm for Components up to 6 x 8 mm - PACE 4038-7002

A square nozzle heats elongated packages unevenly: the short side gets too much hot gas, the long side too little. At 9 x 11 mm this nozzle follows the rectangular footprint of a component up to 6 x 8 mm.

Benefits

• Rectangular 9 x 11 mm nozzle matched to components up to 6 x 8 mm.
• Even reflow across the full solder area of elongated packages.
• Genuine nozzle from the PACE ThermoFlo Nozzle Chart for TF 1700 and TF 2700.

Specifications

Applications

• Rework of rectangular CSP, DFN and memory packages up to 6 x 8 mm
• Replacing small components with unequal edge lengths
