What are Festo CPE valves used for?

Festo CPE valves are used for controlling pneumatic systems with high flow rates and compact design.

What types of actuation do Festo CPE valves support?

Festo CPE valves support both electrically and pneumatically actuated configurations.

Are Festo CPE valves suitable for universal applications?

Yes, Festo CPE valves are designed for universal applications in pneumatic systems.

What is the flow rate capacity of Festo CPE valves?

Festo CPE valves are known for their high flow rate capacity, making them suitable for demanding applications.

How compact are Festo CPE valves?

Festo CPE valves feature a compact design, ideal for spaces with limited room.

Can Festo CPE valves be used in automation systems?

Yes, Festo CPE valves are well-suited for integration into various automation systems.

Where can I purchase Festo CPE valves?

Festo CPE valves can be purchased from authorized Festo distributors and online platforms.

Valve CPE

Universal directional control valves

Festo CPE valves are electrically actuated compact valves for universal valve terminal and individual mounting. The CPE10-M1BH range offers 3/2-way valves in switching functions 3GL (3/2 monostable, working port exhausted) and 3GLS (3/2 monostable, working port blocked), plus 3/2 bistable switching. Port sizes M5, M7, and push-in fittings QS-4 and QS-6 cover the complete miniature valve programme. With over 390 types, the programme addresses all common voltages and wiring concepts.

⚙ CPE10-M1BH compact valve - narrow profile for dense valve terminal population with minimal pitch

✓ 3GL and 3GLS function - 3/2 monostable with working port exhaust (3GL) or blocked (3GLS) in de-energised state

⚡ M5, M7, QS-4 and QS-6 ports - complete range for miniature cylinders, grippers, and micro-dosing

✦ MPA/CPX valve terminal compatible - direct integration into Festo MPA and CPX valve terminal architecture

Type	Function	Port
CPE10-M1BH-3GL-M5	3/2 monostable, exhaust	M5
CPE10-M1BH-3GL-M7	3/2 monostable, exhaust	M7
CPE10-M1BH-3GL-QS-4	3/2 monostable, exhaust	QS-4 (4 mm tube)
CPE10-M1BH-3GL-QS-6	3/2 monostable, exhaust	QS-6 (6 mm tube)
CPE10-M1BH-3GLS-M5	3/2 monostable, blocked	M5

Typical applications: Miniature gripper and vacuum suction cup controls in handling technology, miniature cylinder drives in electronics and precision engineering production, dispensing head controls in liquid dispensing, and high-density valve terminal configurations requiring compact M5/M7 valves.
